Tia Duncan Duncan 1
English 2010
Instructions
How to Change Your OilMost cars are very similar when it comes to an oil change. This paper is based on a Chevy Blazer so there may be some differences depending on the make and model of the car.
Tools that you will need when changing your oil and filter:
Drain Pan
Breaker Bar/ RatchetSocket (must be the correct size to fit the drain plug)
Rubber Gloves (optional)
Filter Wrench
Other things needed:
Motor Oil
Oil Filter
Rags for wiping any spills or cleaning parts
It’s a good idea, if this is your first oil change, to get under your car and familiarize yourself with the locations of the oil drain plug and oil filter, the engine and the exhaust components. They will be warm while you’re working, so try to anticipate any potential problems and how to avoid them before they happen.
Getting Started
Step 1.
Step 2.
Start the engine to allow it to reach normal operating temperature, warm oil and sludge will flow out more easily when warmed. When it is warmed up, turn the engine off and remove the filler cap from the valve cover.
Duncan 2
Start the engine to allow it to reach normal operating temperature, warm oil and sludge will flow out more easily when warmed. When it is warmed up, turn the engine off and remove the filler cap from the valve cover.
Duncan 2
Start the engine to allow it to reach normal operating temperature, warm oil and sludge will flow out more easily when warmed. When it is warmed up, turn the engine off and remove the filler cap from the valve cover.
Duncan 2
Step 3.
Step 4. Allow the old oil to drain into the pan. You may need to move the drain pan farther under the engine as the flow slows to a trickle.
Step 5.
After all the oil has drained, wipe off the drain plug and the area around the drain plug opening with a clean rag. Install the plug and tighten it securely, being careful not to strip the threads.
After all the oil has drained, wipe off the drain plug and the area around the drain plug opening with a clean rag. Install the plug and tighten it securely, being careful not to strip the threads. After all the oil has drained, wipe off the drain plug and the area around the drain plug opening with a clean rag. Install the plug and tighten it securely, being careful not to strip the threads.
Step 6.
Move the drain pan into a position under the oil filter. In the Chevy Blazer it is located remote from the engine but in most cars it’s located off the engine block.
Move the drain pan into a position under the oil filter. In the Chevy Blazer it is located remote from the engine but in most cars it’s located off the engine block. Move the drain pan into a position under the oil filter. In the Chevy Blazer it is located remote from the engine but in most cars it’s located off the engine block.
Step 7.
Loosen the oil filter by turning it counterclockwise with the filter wrench. Once it is loose use your hands to unscrew it and immediately tilt the open end up to prevent the oil inside the filter from spilling out.
Loosen the oil filter by turning it counterclockwise with the filter wrench. Once it is loose use your hands to unscrew it and immediately tilt the open end up to prevent the oil inside the filter from spilling out.
Loosen the oil filter by turning it counterclockwise with the filter wrench. Once it is loose use your hands to unscrew it and immediately tilt the open end up to prevent the oil inside the filter from spilling out.
Step 8.
Step 9.
Step 10.
Remove all tools, rags, drain pan, and anything else that may be under the vehicle, and be careful not to spill any oil from the pan. Then lower the vehicle.
Remove all tools, rags, drain pan, and anything else that may be under the vehicle, and be careful not to spill any oil from the pan. Then lower the vehicle. Remove all tools, rags, drain pan, and anything else that may be under the vehicle, and be careful not to spill any oil from the pan. Then lower the vehicle.
Step 11.
Add the new oil to the engine through the oil filler cap in the valve cover. Use a funnel, if necessary, to prevent oil from spilling onto the top of the engine. Pour three quarts of new oil into the engine and wait a few minutes to allow the oil to fill the oil pan.
Add the new oil to the engine through the oil filler cap in the valve cover. Use a funnel, if necessary, to prevent oil from spilling onto the top of the engine. Pour three quarts of new oil into the engine and wait a few minutes to allow the oil to fill the oil pan. Add the new oil to the engine through the oil filler cap in the valve cover. Use a funnel, if necessary, to prevent oil from spilling onto the top of the engine. Pour three quarts of new oil into the engine and wait a few minutes to allow the oil to fill the oil pan.
Step 12.
Check the level on the oil dipstick. If the oil level is at or near the right level on the dipstick, put the filler cap back on by hand and start the engine. Allow to run for about a minute. While it is running, look under the vehicle and check for leaks at the oil pan drain plug and around the oil filter. If there is a leak, turn off the engine and tighten the plug or filter.
Check the level on the oil dipstick. If the oil level is at or near the right level on the dipstick, put the filler cap back on by hand and start the engine. Allow to run for about a minute. While it is running, look under the vehicle and check for leaks at the oil pan drain plug and around the oil filter. If there is a leak, turn off the engine and tighten the plug or filter.
Check the level on the oil dipstick. If the oil level is at or near the right level on the dipstick, put the filler cap back on by hand and start the engine. Allow to run for about a minute. While it is running, look under the vehicle and check for leaks at the oil pan drain plug and around the oil filter. If there is a leak, turn off the engine and tighten the plug or filter.
Step 13.
Wait a few minutes to allow the oil to trickle down into the oil pan and recheck the levels on the dipstick. If necessary, add enough oil to bring the levels to the correct spot. During the next few trips make sure that the oil levels are proper and not leaking.
Wait a few minutes to allow the oil to trickle down into the oil pan and recheck the levels on the dipstick. If necessary, add enough oil to bring the levels to the correct spot. During the next few trips make sure that the oil levels are proper and not leaking. Wait a few minutes to allow the oil to trickle down into the oil pan and recheck the levels on the dipstick. If necessary, add enough oil to bring the levels to the correct spot. During the next few trips make sure that the oil levels are proper and not leaking.
Step 14.
The old oil can not be reused and should be discarded properly. Don’t pour used oil into drains or onto to the ground; wait till the oil has cooled and pour it into a suitable container (capped plastic jug, milk cartons…) for transporting to a disposal site. Some auto parts stores accept used oil, or go to Earth 911.org to find a recycling center near you.
The old oil can not be reused and should be discarded properly. Don’t pour used oil into drains or onto to the ground; wait till the oil has cooled and pour it into a suitable container (capped plastic jug, milk cartons…) for transporting to a disposal site. Some auto parts stores accept used oil, or go to Earth 911.org to find a recycling center near you.
The old oil can not be reused and should be discarded properly. Don’t pour used oil into drains or onto to the ground; wait till the oil has cooled and pour it into a suitable container (capped plastic jug, milk cartons…) for transporting to a disposal site. Some auto parts stores accept used oil, or go to Earth 911.org to find a recycling center near you.
Compare the old filter with the new filter to make sure it is the same type. Smear some clean oil on the rubber gasket of the new oil filter and screw it into place, because over tightening the filter will damage the gasket. Don’t use the wrench; use your hands to tighten until the gasket contacts with the seating surface. Then seat the filter by giving it an additional ¾ turn.
Duncan 3
With a clean rag, wipe the oil filter mounting surface. Make sure the old gasket isn’t stuck to the mounting surface; you can remove it with a scraper if necessary.
Being careful not to touch the hot exhaust components, place the drain pan under the drain plug and remove the plug. The engine oil drain plug is located at the rear of the oil pan; it is usually very tight, and that is when you can use the breaker/ratchet and socket to help remove the plug. You may want to wear gloves while unscrewing the plug the final few turns because the oil may come out fast.If you’ve done this right, the oil in your car will start flowing out of the oil pan.
It’s important to have full access to underneath your car so the vehicle can be lifted on a hoist, driven onto ramps, or supported by jackstands. Warning: Never get under a vehicle that is supported by only jacks. Jacks are meant to be used only for raising a vehicle to remove and replace wheels; always use jackstands to support the car if you’re placing your body underneath it.
